Second Seat Belt

Fig 1: Front Seat Belt And Related Replacement Components With Torque Specifications
G08546307Courtesy of SUBARU OF AMERICA, INC.

Tightening torque: N.m (kgf-m, ft-lb)

T1: 30 (3.1, 22)

T2: 38 (3.9, 28)

T3: 53 (5.4, 39)
