Non-Turbo Model

WARNING: This page is about a different car, the 2003 Subaru Impreza. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Radiator Sub Fan System Schematic (Non-Turbo Model)
G02621351Courtesy of SUBARU OF AMERICA, INC.
