Fuel Pump Control Module Removal/Installation

WARNING: This page is about a different car, the 2014 Mazda 6. However, it is still accessible from the selected car via links, so may be relevant.

Disconnect the negative battery cable. (See NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION .)
Tip the rear seat back (LH). (See REAR SEAT BACK REMOVAL/INSTALLATION .)
Remove in the order indicated in the table.

Fig 1: Exhaust System Removal/Installation Replacement Components With Torque Specifications
Courtesy of MAZDA MOTORS CORP.
Install in the reverse order of removal.
