Home >> Mazda >> 1988 >> 929 V6-3.0L SOHC >> Repair and Diagnosis >> Powertrain Management >> Ignition System >> Locations

Ignition System: Locations

Fig. 17 ESA (Electronic Spark Advance) System:
