Home >> Lexus >> 2003 >> SC 430 >> Repair and Diagnosis >> Restraints >> Restraints Control Systems >> Seat Belt >> Front Seat Belt With PRETENSIONER >> Components

Front Seat Belt With PRETENSIONER: Components

Fig 1: Identifying Front Seat Belt Components

G03371251

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
