Removal and Installation





A/C CONTROL ASSEMBLY REMOVAL
1. REMOVE RADIO WITH A/C CONTROL ASSEMBLY
2. REMOVE A/C CONTROL ASSEMBLY
Remove the 4 screws and the A/C control assembly.

INSTALLATION
Installation is in the reverse order of removal.
