Engine Coolant Temperature (ECT) Sensor

  1. Turn ignition off. Disconnect negative battery cable. Drain coolant. Remove ECT sensor. Sensor is located on left front of engine.
  2. With sensing portion of ECT sensor submerged in water measure resistance between terminals. See Figure. Replace ECT sensor if resistance is not as specified. See ECT SENSOR RESISTANCE table.
