Heater Unit

Heater unit
1. Drain engine coolant from the drain cock of radiator.
2. Remove the heater hose from heater pipe.
3. Remove the instrument panel. Dashboard / Instrument Panel
4. Remove the connector.
5. Remove mounting bolt and remove heater unit.




6. Install in reverse order of removal.
