Installation

INSTALLATION




1. Carefully lower the door glass (2) into the door through the window opening.

2. Rotate the door glass into position and engage it to the window regulator glass clamps making sure the glass and lift plates are properly seated.

3. Using the regulator (4), move the front door glass up or down as required to access to the two window regulator glass clamp bolts (3).




4. Tighten the bolts in each of the window regulator glass clamps to 12 Nm (105 in. lbs.).




5. Install the watershield (1) onto the inside of the front door (2).
