Connecting Rod Bearing Cap
Connecting Rod Bearing Cap
Reinstall the bearing half and cap, and torque the bolts.
Tightening torque : 22.6 - 26.5 Nm (2.3 - 2.7 kgf.m, 16.6 - 19.5 lb-ft)+ 98 - 102°
NOTE: Do not turn the crankshaft.
Connecting Rod Bearing Cap
Reinstall the bearing half and cap, and torque the bolts.
Tightening torque : 22.6 - 26.5 Nm (2.3 - 2.7 kgf.m, 16.6 - 19.5 lb-ft)+ 98 - 102°
NOTE: Do not turn the crankshaft.
