Connecting Rod, Engine
a Refer to the Cylinder Head Distortion procedure.
ROD BEARING CAP
Install the connecting rod cap and tighten the bolts in 2 stages.
Stage 1: Tighten to 45 Nm (33 lb-ft).
Stage 2: Tighten to 68 Nm (50 lb-ft).
a Refer to the Cylinder Head Distortion procedure.
ROD BEARING CAP
Install the connecting rod cap and tighten the bolts in 2 stages.
Stage 1: Tighten to 45 Nm (33 lb-ft).
Stage 2: Tighten to 68 Nm (50 lb-ft).
