Acceleration Controls






The system does not use an accelerator cable. Instead, the system uses an accelerator sensor assembly located on the accelerator pedal assembly. This drive by wire system is entirely electronic, and except for the accelerator pedal assembly, does not use mechanically moving parts. The accelerator sensor assembly is not adjustable.
