Power Lock Switch - Installation

INSTALLATION






NOTE: A battery reconnect procedure must be performed anytime the battery has been disconnected. Battery Reconnection .

1. Install window/lock switch (2) to door trim panel and snap into place.
2. Install door trim panel Front Door Trim Panel - Installation.
3. Connect battery negative cable.
