Installation - Engine Fuse Block

Fig 1: Removing/Installing Engine Fuse Block
GC0035891Courtesy of CHRYSLER LLC
  1. Install the engine fuse onto the studs.
  2. Install the plate and the electrical lead to the engine fuse block.
    Fig 2: Identifying Engine Fuse Block Lid
    GC0035890Courtesy of CHRYSLER LLC
  3. Connect the negative battery cable.
  4. Close the lid (1) to the engine fuse block.
  5. Close the hood.
