Circuit Breaker
Component ID: 53
Component : CIRCUIT BREAKER
Connector:
Name : CIRCUIT BREAKER
Color :
# of pins : 2
Pin Description Circuit
1 ACCESSORY DELAY RELAY OUTPUT F981 12PK/YL
2 FUSED ACCESSORY DELAY RELAY OUTPUT F30 14PK/YL
Component ID: 53
Component : CIRCUIT BREAKER
Connector:
Name : CIRCUIT BREAKER
Color :
# of pins : 2
Pin Description Circuit
1 ACCESSORY DELAY RELAY OUTPUT F981 12PK/YL
2 FUSED ACCESSORY DELAY RELAY OUTPUT F30 14PK/YL
