Oil Pressure Sensor: Description and Operation

The PCM monitors the engine oil pressure switch (1) signal to determine if the engine oil pressure is Ok. If the PCM determines that a low oil pressure condition exists, the PCM will communicate the information over the Class II circuit to the IPC and it will illuminate the indicator lamp.
