Garage Door Opener Control Module, Rearview Camera System Control Module, Near Field Communication Control Module, Near Field Communication Control Module 2, Fuse Panel F, Fuse Panel 3
J530
Garage Door Opener Control Module
J772
Rearview Camera System Control Module
J1169
Near Field Communication Control Module
J1170
Near Field Communication Control Module 2
SF
Fuse Panel F
ST3
Fuse Panel 3
SF11
Fuse 11 (On Fuse Panel F)
SF12
Fuse 12 (On Fuse Panel F)
SF13
Fuse 13 (On Fuse Panel F)
T4ih
4-Pin Connector, Black
T5cy
5-Pin Connector, Black
T5d
5-Pin Connector, Black
T8o
8-Pin Connector, Black
T17p
17-Pin Connector, Black
T17px
17-Pin Connector, Blue
T21a
21-Pin Connector, Black
T21ax
21-Pin Connector, Black
TCPM
Coupling Point on Instrument Panel, Center
TTVL
Left Front Door Coupling Point
*
Refer to Applicable Wiring Diagram for the Garage Door Opener
*2
Refer to Applicable Wiring Diagram for the Rearview Camera (Rear Assist)
*3
Depending on Equipment
*4
For Vehicles with Rearview Camera System
*5
For Vehicles with Garage Door Opener
