Central Locking Overview
- 1 - Front passenger door control module J387
- 2 - Anti-theft alarm system sensor -G578-
- 3 - Right rear door control module J389
- 4 - Comfort system central control module J393
- 5 - Fuel filler door unlock motor -V155-
- 6 - Vehicle positioning system interface control module J843
- Under luggage compartment side trim (right-side)
- 7 - Rear spoiler control module J223
- 8 - Rear lid unlock motor -V139-
- 9 - Left rear door control module J388
- 10 - Driver door control module J386
- 11 - Engine hood contact switch -F266-
